Paviland^® Drenante

Technical Caracteristics

Product made with cement, limestone aggregates of controlled grain size and additives that improve its plasticity and workability properties.

Advantages and Uses

• Sports courts.
• Car parks.
• Flooring in residential developments.
• Cycle and pedestrian lanes.
• Car washes.
• Tree pits and landscaping.
• Swimming pool enclosures and surroundings.
• Roundabouts.
• Base for artificial turf.
• Any surface where you want to avoid pooling of water and liquids.

Application Procedure

• Mix the product to 7% of water (approximately 1.75 liters of water per 25 kilogram bag) to get a dry consistency. Mix whole sacks. Mechanical mixing of the mixture is recommended to get a smooth paste without lumps.
• The ideal consistency of PAVILAND Drainage should be such that a handful of the product picked up should not crumble (for lack of water), or lose its structure of holes with the paste flowing between the aggregates (for excess of water).

Recommendations

• Design the system according to the desired drainage capacity and the characteristics of adjacent land.
• On surfaces with slopes greater than 1% additional measures should be taken such as installing barriers or preparing the site in the form of terraces.
• A clean gravel base can be used of a size of between 3 - 12 mm depending on the design and water evacuation capacity that this design requires. The gravel should be completely compacted and leveled to achieve a firm and stable base.
• The thickness of application will vary according to the area where the product is being applied; a minimum of 4 cm for areas without transit, 5 cm for areas with pedestrian transit and 7 cm for areas with light traffic.
• Compact the product sufficiently to achieve the desired resistances by hitting with a trowel or something similar or by gentle leveling with a vibrating leveler such that all the grains stay within the mortar of the product, avoid troweling and smoothing so as not to block the pore.
• Work joints should be made beforehand using flexible battens or something similar. Make partition joints every 30 m² immediately after the consolidation of the product using a steel joint profile or something similar. Respect perimeter and structural joints.
• Ensure the product cures properly either by covering it for at least 3 days with a thick geotextile or else by applying a powdered curing resin for concrete type DC-2 over the surface once the product does not stain the hand.

MAINTENANCE is recommended, following these recommendations:

• When doing the design, the measures to be implemented in the surrounding land should be taken into account so as to prevent materials being swept towards paved surfaces. Earth, stones, leaves and other materials may get through the holes in the flooring preventing the flow of water and thus reducing the usefulness of the drainage flooring.
• Cleaning is required at least once a year to remove dirt from the surface of the flooring. Cleaning can be done using pressurized air or water.
• Do not apply the product in conditions of strong wind or rain, or at temperatures below 5⁰C or above 35⁰C.
• High temperatures may accelerate the setting process and low temperature may slow it down.
• Do not add water if the product has started to set.
• Do not use sea water or water of uncertain characteristics for the mixing.
• It should be noted that an increase of mixing water means a decrease in resistances and loss of porosity.
• Do not paint, or carry out any other treatment that obstructs the porosity of the product, this pressure to avoid damaging the floor.

Packaging and Storage

Plastic bags of 25 kg.
Shelf life: 12 months in its sealed original packaging, sheltered from weather conditions and humidity.

Technical data

(Statistical data obtained under standard conditions)

Notas

The information and instructions in this datasheet are based on our current tests and technical knowledge. They are intended as general guidance and do not constitute a binding commitment by PIDILITEPUMA MEA CHEMICALS LLC. It is the sole responsibility of the user to verify, prior to use, that the product is suitable for the intended application and to ensure that it is applied correctly and in accordance with applicable regulations and good industry practice.

PIDILITEPUMA MEA CHEMICALS LLC cannot control how its products are applied on site throughout the entire project and therefore cannot accept responsibility for their application by contractors or other parties involved in the execution of the work. Support visits to the jobsite by our technical staff do not change that. Our responsibility is limited exclusively to defects that can be directly attributed to the supplied products, whether used individually or as part of a system, caused by manufacturing defects.

It is the responsibility of the project designer, site manager, contractor, or other relevant professionals to ensure that the selected products are appropriate for the specific project, taking into account their properties, the substrate, site conditions, and any existing issues.

In the event of a claim, the original packaging must be provided to ensure proper product traceability.

Any performance values stated for PIDILITEPUMA MEA CHEMICALS LLC products or construction solutions, whether in UNE standards or other applicable standards, are based solely on the specific test conditions defined in those standards (such as substrate type, temperature, and humidity). These values may not apply to situations where products are tested or used under different conditions.
